Harvard Center for Biological Imaging
HCBI: Zeiss Lightsheet Short-Term Use
HCBI: Zeiss Lightsheet Short-Term Use

Long-term, high-speed 3D imaging with virtually no phototoxicity or bleaching may sound too good to be true, but the Lightsheet.Z1 delivers. This brand new microscope from ZEISS is the first of its kind to be installed in North America! Samples are immobilized in agarose or tubing, immersed in a buffer of your choosing, and can be freely rotated during imaging. 3D imaging that previously took hours on a point scanner can now be accomplished in mere minutes!

> reserve today (requires login)

HCBI: Zeiss Lightsheet Time-Lapse
HCBI: Zeiss Lightsheet Time-Lapse

This calendar is for time-lapse experiments and is available on Tuesdays at 8:00 pm through Mondays at 8:00 am. Reservations will be limited to one per researcher/research group per week.

> reserve today (requires login)

HCBI: Zeiss ELYRA
HCBI: Zeiss ELYRA

Widefield, laser widefield, TIRF, spectral confocal imaging, and super-resolution? The ELYRA can do it all! Using structured illumination, this system can improve resolution in X, Y, and Z two-fold – with no special sample prep needed. If that isn’t sufficient for your experiment, photomanipulation super-resolution techniques like PALM or dSTORM can improve your resolution by as much as an order of magnitude! Clicking a button in the ZEISS software easily switches between imaging modes, allowing you to image the same sample by a variety of techniques.

> reserve today (requires login)

HCBI: Zeiss 880 + Airyscan + Incubation Weekdays
HCBI: Zeiss 880 + Airyscan + Incubation Weekdays

The LSM 880 confocal microscope offers 34-channels of supreme sensitivity, owing to its GaAsP detectors with the added bonus of a super-resolution Airyscanner. This extraordinary point scanner can simultaneously image and spectrally separate up to 10 different dyes, create high resolution 3D images over large tiled areas, or image single molecules through fluorescence correlation techniques. The unparalleled sensitivity of this system also makes it the ideal live-cell imaging point scanner, allowing for high-speed confocal acquisition with brilliant signal to noise ratios. The Airy Scan array detector removes the requirement for a pinhole allowing ALL of the light collected from your sample to reach the detector. And additional deconvolution provides a 1.7x improvement over the theoretical diffraction limit.

> reserve today (requires login)

HCBI: Zeiss 880 + Airyscan + Incubation Off Hours
HCBI: Zeiss 880 + Airyscan + Incubation Off Hours

The LSM 880 confocal microscope offers 34-channels of supreme sensitivity, owing to its GaAsP detectors with the added bonus of a super-resolution Airyscanner. This extraordinary point scanner can simultaneously image and spectrally separate up to 10 different dyes, create high resolution 3D images over large tiled areas, or image single molecules through fluorescence correlation techniques. The unparalleled sensitivity of this system also makes it the ideal live-cell imaging point scanner, allowing for high-speed confocal acquisition with brilliant signal to noise ratios. The Airy Scan array detector removes the requirement for a pinhole allowing ALL of the light collected from your sample to reach the detector. And additional deconvolution provides a 1.7x improvement over the theoretical diffraction limit.

> reserve today (requires login)

HCBI: AxioZoom V16
HCBI: AxioZoom V16

Combining a 16x zoom with high numerical aperture objectives, the AxioZoom.V16 offers superior brightness in large object fields. This highly versatile microscope can image samples illuminated by transmitted, reflected, polarized, and fluorescent light sources, and is equipped with high resolution color and monochrome cameras. The AxioZoom.V16 also boasts an Apotome, an optical sectioning device, capable of creating large field 3D images.

> reserve today (requires login)

HCBI: LSM 700 Inverted Confocal
HCBI: LSM 700 Inverted Confocal

So you have a four-color sample that requires 3D imaging over large tiled areas? Then the LSM 700 is the microscope for you. This incredibly user-friendly point scanner can image four channels simultaneously, due to its unique Variable Secondary Dichroic, all the while acquiring 3D images over multiple fields of view.

> reserve today (requires login)

HCBI: PALM Laser Microdissection Microscope
HCBI: PALM Laser Microdissection Microscope

Even the world’s greatest surgeon might struggle with dissecting single cells out of a slice of tissue. With the PALM system, laser microdissection, catapult and capture is as easy as drawing a region to dissect on the screen, and pressing start. Remove individual cells from your samples slices, or excise entire subregions for RT-PCR, DNA, or even mass spec analysis.

> reserve today (requires login)

HCBI: Zeiss Axio Scan.Z1
HCBI: Zeiss Axio Scan.Z1

Have you ever looked at a giant pile of slides, and wondered how you'll find the time to image them all? The Axio Scan.Z1 is your answer! This high speed slide scanner has an astonishing 100-slide capacity, and can image samples stained with both colormetric and fluorescent dyes. Load your slides, let the software automatically locate your tissue sections, and off you go!

> reserve today (requires login)

HCBI: LSM 700 Inverted Confocal (preferred Lichtman Lab)
HCBI: LSM 700 Inverted Confocal (preferred Lichtman Lab)

LSM 700 confocal (from Lichtman lab) running on the new ZEN-software. Inverted microscope with manual stage. Lasers: 405, 488, 555, 635

> reserve today (requires login)

HCBI: Zeiss LSM Pascal Inverted
HCBI: Zeiss LSM Pascal Inverted

The LSM Pascal is a very user-friendly two-channel confocal, capable of imaging over large areas and 3D imaging. This system uses traditional filter-based fluorescence emission, and has a separate pinhole for each detector – offering greater control over your optical section thickness.

> reserve today (requires login)

HCBI: Zeiss LSM Pascal Inverted (Preferred: Schier Lab)
Members of lab that donated instrument may sign-up in advance.
> reserve today (requires login)
HCBI: Training 2: Christian Hellriegel
HCBI: Training 2: Christian Hellriegel

Trains on all microscopes.

> reserve today (requires login)

HCBI: Training 1: Erin Diel
HCBI: Training 1: Erin Diel

Trains on all microscopes.

> reserve today (requires login)

HCBI: X-CLARITY Tissue Clearing System
HCBI: X-CLARITY Tissue Clearing System

> reserve today (requires login)

HCBI: Zeiss 880 Inverted #2 Off Hours
HCBI: Zeiss 880 Inverted #2 Off Hours

> reserve today (requires login)

HCBI: Zeiss 880 Inverted #2 Weekdays
HCBI: Zeiss 880 Inverted #2 Weekdays

> reserve today (requires login)

HCBI: Zeiss 2-Photon Short-Term
HCBI: Zeiss 2-Photon Short-Term

Two-photon illumination has always appealed to biologists for imaging deep into living tissue. But did you ever imagine probing more than 5mm into your sample? Using the 780 NLO with our specialized SCAlE objective, you can visualize deep into clarified tissue with incredible resolution. Even without clarifying your samples, this microscope excels at penetrating deep into live or fixed specimens, and creating beautiful 3D datasets.

> reserve today (requires login)

HCBI: LSM 880 Upright #2
HCBI: LSM 880 Upright #2

The LSM 880 on an AxioImager upright stand offers the flexibility of both spectral and traditional fluorescence 3D imaging on the same system. With a few simple clicks in the software, you can precisely select emission window for all 3 detectors, or run in spectral mode. The system is also compatible with our Sca/e and CALRITY long working distance objectives for imaging cleared tissue.

> reserve today (requires login)

HCBI: Cell Discoverer
HCBI: Cell Discoverer

Trying to reproduce physiological conditions for cells in a petri dish is always a challenge, but the CELL DISCOVERER system makes it easy! This inverted microscope is fully enclosed in a heated incubator box, and features a heated stage with a humidified CO2 microenvironment. And if you’re interested in long term imaging, feel free to ask us about Definite Focus, the focus maintenance system which makes sure your sample doesn’t drift over time.

> reserve today (requires login)

HCBI: 20x Clearing Objective
HCBI: 20x Clearing Objective

20x Clearing Objective

> reserve today (requires login)

HCBI: Zeiss Axio Scan.Z1 #2
HCBI: Zeiss Axio Scan.Z1 #2

Have you ever looked at a giant pile of slides, and wondered how you'll find the time to image them all? The Axio Scan.Z1 is your answer! This high speed slide scanner has an astonishing 100-slide capacity, and can image samples stained with both colormetric and fluorescent dyes. Load your slides, let the software automatically locate your tissue sections, and off you go!

> reserve today (requires login)

HCBI: SmartClear II Pro
HCBI: SmartClear II Pro

> reserve today (requires login)

HCBI: Training 1: Doug Richardson
HCBI: Training 1: Doug Richardson

Trains on all microscopes.

> reserve today (requires login)

HCBI: Graphics Workstation 1: Imaris, Volocity

High-end PC for graphics work running Volocity software from Improvision for 3D rendering and analysis of data including confocal data sets. In addition, this computer runs the free image-processing packages ImageJ and Fiji.

> reserve today (requires login)

HCBI: Zeiss 2-Photon Time-Lapse
HCBI: Zeiss 2-Photon Time-Lapse

Two-photon illumination has always appealed to biologists for imaging deep into living tissue. But did you ever imagine probing more than 5mm into your sample? Using the 780 NLO with our specialized SCAlE objective, you can visualize deep into clarified tissue with incredible resolution. Even without clarifying your samples, this microscope excels at penetrating deep into live or fixed specimens, and creating beautiful 3D datasets.

> reserve today (requires login)

HCBI: Graphics Workstation 2: ZEN Blue/Black (all modules), Cell Profiler

High-end PC for graphics work which includes a number of ZEN Black and ZEN Blue releases. The station is primarily used for processing 3DSIM and PALM/STORM data.

> reserve today (requires login)

HCBI: Graphics Workstation 3: ZEN Black(Lightsheet), Arivis

High-end PC for graphics work running ZEN Black Lightsheet addition. The computer features 15TB of data storage and is EXCLUSIVELY used for processing data sets acquired on the Lightsheet microscope.

> reserve today (requires login)

HCBI: Graphics Workstation 4: ZEN Blue/Black (all modules), Arivis, Cell Profiler

> reserve today (requires login)

HCBI: Graphics Workstation 5: ZEN Blue/Black Stitching and Intellisis modules

> reserve today (requires login)
